Yedoo Mezeq inklusive antenn [Skickas direkt från fabrik]

Technical details

Attention! Components may vary depending on current availability. More

Product number

12608

Loading limit

150 kg / 330 lb

Min. height of rider

150 cm / 59 in

Weight (with/without kickstand)

11 / 10,7 kg // 24.3 / 23.6 lb

Box size

105 x 64 x 18 cm (41.3 x 25.2 x 7.1 in)

Box weight

13 / 28.7 lb

Frame

YEDOO Hi-ten steel

Fork

YEDOO Hi-ten steel

Stem

ZOOM alloy

Handlebar

YEDOO Cross alloy

Grips

Ergonomic (with anti-rotation lock)

Headset

NECO alloy 1 1/8" threaded

Brake levers

TEKTRO alloy

Brakes (front/rear)

2x Disc TEKTRO ARIES

Wheels

20" / 16"

Rims

HJC alloy double wall

Hubs

NOVATEC disc

Hub width (front/rear)

100 / 100 mm // 3.9 / 3.9 in

Preparation for using flat screws (front/ rear)

No / No

Bearings

Industrial

Quick-release levers (front/rear)

Yes / Yes

Tyres (front/rear)

KENDA / INNOVA / 20x2,25 / 16x2,25

Max. inflation (front/rear)

4,6 bar / 4,5 bar

Preparation for bottle holder

2x

Kickstand

Yedoo central, integrated

Reflective elements

No

Dimensions

[1] Length

148 cm / 58.3 in

[2] Footboard

40 cm / 15.7 in

[3] Handlebar height

95 -101 cm / 37.4 - 39.8 in

[4] Width of handlebars

64 cm / 25.2 in

[5] Ride height (higher/lower position)*

6 cm / 2.4 in

[6] Distance between footboard and ground (higher/lower position)*

9,5 cm / 3.7 in

[7] Room for rider

59 cm / 23.2 in

*Tolerance +-0.2 cm

Documents, standards and certificates

Manual

Manual_Yedoo_Adult_scooters_2020_2016_1616_web.pdf

Norms

ČSN EN 14619

Testing authority

SZÚ, s. p.

Quality and Safety Certificate RunRun

We don’t just brag that our products have performance and quality built to last – we’ve proved it by extending the full warranty to 3 YEARS! More

Yedoo frames are protected by registered EU industrial designs. The Yedoo brand, along with the trade names of each model, are trademark protected.

Change of technical parameters and components reserved.

• Technical details

• Generation Y40

• Product number

  12608 - Y40

• Loading limit

  150 kg / 330 lb

• Min. height of rider

  150 cm / 59 in

• Weight (with/without kickstand)

  10,9 / 10,5 kg // 24.3 / 23.1 lb

• Box size

  106 x 66 x 18 cm (41.7 x 26.0 x 7.1 in)

• Box weight

  12,8 kg / 28.2 lb

• Frame

  YEDOO Hi-ten steel

• Fork

  YEDOO Hi-ten steel

• Stem

  ZOOM alloy

• Handlebar

  YEDOO Cross alloy

• Grips

  Ergonomic (with anti-rotation lock)

• Headset

  NECO alloy 1 1/8" threaded

• Brake levers

  TEKTRO ML 520 alloy

• Brakes (front/rear)

  2x Disc TEKTRO MD-M300 ARIES

• Wheels

  20" / 16"

• Rims

  HJC alloy double wall

• Hubs

  NOVATEC disc

• Hub width (front/rear)

  100 / 100 mm // 3.9 / 3.9 in

• Preparation for using flat screws (front/ rear)

  No / No

• Bearings

  Industrial

• Quick-release levers (front/rear)

  Yes / Yes

• Tyres (front/rear)

  KENDA 20x2,25 / 16x2,25

• Max. inflation (front/rear)

  4,6 bar / 4,6 bar

• Preparation for bottle holder

  1x

• Kickstand

  YEDOO

• Reflective elements

  No

• Note

  Inovovaný model generace Y40

• Dimensions

•

• [1] Length

  152,5 cm / 60.0 in

• [2] Footboard

  40 cm / 15.7 in

• [3] Handlebar height

  92 - 98 cm / 36.2 - 38.6 in

• [4] Width of handlebars

  65,5 cm / 25.8 in

• [5] Ride height (higher/lower position)*

  5 cm / 2.0 in

• [6] Distance between footboard and ground (higher/lower position)*

  8,5 cm / 3.3 in

• [7] Room for rider

  62 cm / 24.4 in

• *Tolerance +-0.2 cm

• Documents, standards and certificates

•

  We don’t just brag that our products have performance and quality built to last – we’ve proved it by extending the full warranty to 3 YEARS! More

• Change of technical parameters and components reserved.
