Yedoo Mezeq inklusive antenn [Skickas direkt från fabrik] Tillfälligt slut

Yedoo Mezeq inklusive antenn [Skickas direkt från fabrik] Tillfälligt slut

He’s not much of a talker. He is headstrong and feels best in the field. Or when going fishing. With a load capacity of up to 150 kg and disc brakes on both wheels, he can handle anything. He navigates urban jungle, roots, mud and wet pine needles with ease. Riding.

Technical details
Attention! Components may vary depending on current availability. More
Product number
12608
Loading limit
150 kg / 330 lb
Min. height of rider
150 cm / 59 in
Weight (with/without kickstand)
11 / 10,7 kg // 24.3 / 23.6 lb
Box size
105 x 64 x 18 cm (41.3 x 25.2 x 7.1 in)
Box weight
13 / 28.7 lb
Frame
YEDOO Hi-ten steel
Fork
YEDOO Hi-ten steel
Stem
ZOOM alloy
Handlebar
YEDOO Cross alloy
Grips
Ergonomic (with anti-rotation lock)
Headset
NECO alloy 1 1/8" threaded
Brake levers
TEKTRO alloy
Brakes (front/rear)
2x Disc TEKTRO ARIES
Wheels
20" / 16"
Rims
HJC alloy double wall
Hubs
NOVATEC disc
Hub width (front/rear)
100 / 100 mm // 3.9 / 3.9 in
Preparation for using flat screws (front/ rear)
No / No
Bearings
Industrial
Quick-release levers (front/rear)
Yes / Yes
Tyres (front/rear)
KENDA / INNOVA / 20x2,25 / 16x2,25
Max. inflation (front/rear)
4,6 bar / 4,5 bar
Preparation for bottle holder
2x
Kickstand
Yedoo central, integrated
Reflective elements
No
Dimensions
[1] Length
148 cm / 58.3 in
[2] Footboard
40 cm / 15.7 in
[3] Handlebar height
95 -101 cm / 37.4 - 39.8 in
[4] Width of handlebars
64 cm / 25.2 in
[5] Ride height (higher/lower position)*
6 cm / 2.4 in
[6] Distance between footboard and ground (higher/lower position)*
9,5 cm / 3.7 in
[7] Room for rider
59 cm / 23.2 in
*Tolerance +-0.2 cm
Documents, standards and certificates
Manual
Manual_Yedoo_Adult_scooters_2020_2016_1616_web.pdf
Norms
ČSN EN 14619
Testing authority
SZÚ, s. p.
Quality and Safety Certificate RunRun
We don’t just brag that our products have performance and quality built to last – we’ve proved it by extending the full warranty to 3 YEARS! More
Yedoo frames are protected by registered EU industrial designs. The Yedoo brand, along with the trade names of each model, are trademark protected.
Change of technical parameters and components reserved.
- Technical details
- Generation Y40
- Product number
  12608 - Y40
- Loading limit
  150 kg / 330 lb
- Min. height of rider
  150 cm / 59 in
- Weight (with/without kickstand)
  10,9 / 10,5 kg // 24.3 / 23.1 lb
- Box size
  106 x 66 x 18 cm (41.7 x 26.0 x 7.1 in)
- Box weight
  12,8 kg / 28.2 lb
- Frame
  YEDOO Hi-ten steel
- Fork
  YEDOO Hi-ten steel
- Stem
  ZOOM alloy
- Handlebar
  YEDOO Cross alloy
- Grips
  Ergonomic (with anti-rotation lock)
- Headset
  NECO alloy 1 1/8" threaded
- Brake levers
  TEKTRO ML 520 alloy
- Brakes (front/rear)
  2x Disc TEKTRO MD-M300 ARIES
- Wheels
  20" / 16"
- Rims
  HJC alloy double wall
- Hubs
  NOVATEC disc
- Hub width (front/rear)
  100 / 100 mm // 3.9 / 3.9 in
- Preparation for using flat screws (front/ rear)
  No / No
- Bearings
  Industrial
- Quick-release levers (front/rear)
  Yes / Yes
- Tyres (front/rear)
  KENDA 20x2,25 / 16x2,25
- Max. inflation (front/rear)
  4,6 bar / 4,6 bar
- Preparation for bottle holder
  1x
- Kickstand
  YEDOO
- Reflective elements
  No
- Note
  Inovovaný model generace Y40
- Dimensions
- [1] Length
  152,5 cm / 60.0 in
- [2] Footboard
  40 cm / 15.7 in
- [3] Handlebar height
  92 - 98 cm / 36.2 - 38.6 in
- [4] Width of handlebars
  65,5 cm / 25.8 in
- [5] Ride height (higher/lower position)*
  5 cm / 2.0 in
- [6] Distance between footboard and ground (higher/lower position)*
  8,5 cm / 3.3 in
- [7] Room for rider
  62 cm / 24.4 in
- *Tolerance +-0.2 cm
- Documents, standards and certificates
- We don’t just brag that our products have performance and quality built to last – we’ve proved it by extending the full warranty to 3 YEARS! More
- Change of technical parameters and components reserved.
